Adventures in Tic-Tac-Toe with React

February 23, 2024

Why

First off, tic-tac-toe is pretty simple and probably over done, but I think this tutorial series is not going to focus on the problem (the actual game), but on to construct the overall architecture of building a React app.

What

This is what we will focus on the following:

building a simple version which has many problems
improve the simple version
make it a general game (NxN board)
introduce some functional programming concepts
better UI (HTML canvas)
how about some AI?
how about even more AI?
play against another player
even better UI (3D graphics)

Simple Version

We’ll use Vite, so lets create the app by doing: npm create vite@latest and answer the following prompts with React and Typescript.
cd into the directory and npm run dev
We will quickly build the code and then we’ll update this so it extensible and testable.

Create a directory: components and create file in there TicTacToe.tsx and TicTacToe.css Add the following to TicTacToe.tsx:

const TicTacToe = () => {
  return <div>tictactoe</div>;
};

export default TicTacToe;

Open App.tsx and delete the content and the component.

Lets use CSS grid for the layout…add the following to the TicTacToe.css file:

grid {
  display: grid;
  grid-template-columns: 100px 100px 100px;
  grid-template-rows: 100px 100px 100px;
}

.grid > div {
  border: 1px solid gray;
  display: flex;
  justify-content: center;
  align-items: center;
}

Lets also think about state.

Track which players turn it is
What value each square in the has (empty, X, O)

Lets use an array for the state and a variable for the turn.

const [gameStates, setGameStates] = React.useState<GameState[]>(() =>
    Array(9).fill(GameState.Empty)
  );

add this type:

enum GameState {
  Empty = '',
  X = 'X',
  O = 'O',
}

TicTacToe should return this:

  return (
    <div className="grid">
      {gameStates.map((state, i) => (
        <div key={i}>{state}</div>
      ))}
    </div>
  );

We need to handle a click. Our callback will get the index and we’ll set the player in the array. Player 1 will be X and player 2 will be Y.

change the div line to this: <div key={i} onClick={() => handleClick(i)}>

add the handleClick function:

 const handleClick = React.useCallback(
  (i: number) => {
    const newGameState = [...gameStates];
    newGameState[i] = playerTurn === PlayerTurn.One ? GameState.X : GameState.O;
    setGameStates(newGameState);
    setPlayerTurn(playerTurn === PlayerTurn.One ? PlayerTurn.Two : PlayerTurn.One);
  },
  [gameStates, playerTurn]
);

We need the PlayerTurn:

enum PlayerTurn {
  One,
  Two,
}

and its state: const [playerTurn, setPlayerTurn] = React.useState(PlayerTurn.One);

Right now, you can click the square and it will overwrite the previous value and there is no logic…lets add that.

Answer


  if (gameStates[i] !== GameState.Empty) {
        return;
  }

Add a message to the top of the component describing whose turn it is (also this will be the place where will be show the winner or tie).

Answer


{showGameMessage(playerTurn)}


const showGameMessage = (turn: PlayerTurn) => {
  return turn === PlayerTurn.One ? 'Player 1 turn' : 'Player 2 turn';
};


.message {
  margin: 10px;
}

And now for the fun part…lets detect when the game is won or tied:

Note: there are multiple ways to solve this…

const showGameMessage = (state: GameState[], turn: PlayerTurn) => {
  const status = getGameStatus(state, turn);
  if (status) return status;
  return turn === PlayerTurn.One ? 'Player 1 turn' : 'Player 2 turn';
};

const getGameStatus = (state: GameState[], turn: PlayerTurn) => {
  if (checkTie(state)) {
    return 'Game Tied';
  }
  if (checkRows(state)) {
    return turn === PlayerTurn.One ? 'Player 2 Wins!' : 'Player 1 Wins!';
  }
  if (checkColumns(state)) {
    return turn === PlayerTurn.One ? 'Player 2 Wins!' : 'Player 1 Wins!';
  }
  if (checkDiagonals(state)) {
    return turn === PlayerTurn.One ? 'Player 2 Wins!' : 'Player 1 Wins!';
  }
  return '';
};

const checkTie = (state: GameState[]) => {
  return !state.some((x) => x === GameState.Empty);
};

const checkRows = (state: GameState[]) => {
  if (state[0] !== GameState.Empty && state[0] === state[1] && state[1] === state[2]) return true;
  if (state[3] !== GameState.Empty && state[3] === state[4] && state[4] === state[5]) return true;
  if (state[6] !== GameState.Empty && state[6] === state[7] && state[7] === state[8]) return true;
  return false;
};

const checkColumns = (state: GameState[]) => {
  if (state[0] !== GameState.Empty && state[0] === state[3] && state[3] === state[6]) return true;
  if (state[1] !== GameState.Empty && state[1] === state[4] && state[4] === state[7]) return true;
  if (state[2] !== GameState.Empty && state[2] === state[5] && state[5] === state[8]) return true;
  return false;
};

const checkDiagonals = (state: GameState[]) => {
  if (state[0] !== GameState.Empty && state[0] === state[4] && state[4] === state[8]) return true;
  if (state[2] !== GameState.Empty && state[2] === state[4] && state[4] === state[6]) return true;
  return false;
};

btw, there is one bug…find it and fix it!

Questions to think about:

How do we test this?
How do we separate out the logic and UI?
How to check for a general case for a NxN grid?
More efficient way to check for a tie?

Some features to add:

Add a New Game button
Keep track of wins/losses/ties
Improve the UI experience
